Standardi WTH -sarja hitsattu hydraulisylinteri
Olemme Kiinassa sijaitsevien hydraulisten sylinterien luotettava valmistaja ja viejä. Valmistus- ja laatujärjestelmämme on suunniteltu tarjoamaan jokaiselle asiakkaalle paras tuote, joka sopii heidän vaatimuksiinsa. Jokaiselle Toleng-standardille WTH-sarja hitsattu hydraulisylinteri on läpikäynyt tiukan korkeapaineisen testauksen, ja siinä on 12 kuukauden takuu.
Lähetä kysely
Tuotteen Kuvaus
Tolengin luotettavalla standardi WTH-sarja hitsattuja hydraulisylinteriä on taottu ristiinputken pohja ja reikä-nasta-silmä. Siinä on kestävä hitsattu rakenne, korkean vetovoiman sauva, jossa on kova kromi pinnoitus ja induktion kovettuminen parannetun lujuuden ja kestävyyden saavuttamiseksi. Hiottu teräsputki varmistaa tarkan liikkeen, kun taas mäntä ja rauhaset on valmistettu sitkeysraudasta lisäämään sitkeyttä.
Tavalliset WTH -hydrauliset sylinterit sopivat monenlaisiin teollisuussovelluksiin ja ovat yleisiä Pohjois -Amerikan teollisuusmarkkinoilla. Niissä on suljettu hydraulinen järjestelmä saastumisen estämiseksi ja optimaalisen suorituskyvyn ylläpitämiseksi haastavissa olosuhteissa.
Standardi Wth -sarjan hitsatut hydraulisylinterin tekniset parametrit
1.työpaine: 3000 psi
2.Rod: teräs, induktio kovettunut ja kromattu
3.Piston: Ductive rauta, lisääntyneen kestävyyden kannalta
4.Tube: Teräs, hiottu ja tarkkuus valmis
5.Rand: Kierretty
6.Pin: Teräs, sinkki päällystetty
7.Seals: Hallite, Aston, NOK, DZ jne. Huippulaatu. Muokattavissa.
8.Paint: Musta, vihreä, punainen, keltainen jne. Mukautettuja värejä on saatavana.
Standardi Wth -sarjan hitsatut hydraulisylinterin tekniset parametrit
| Hitsattu reiän sylinterin läpi | |||||||
| Osanumero | Sauva HALKAISIJA |
Poraus & Sidos |
MITAT | Satamakoko | Nasta KOKO |
PAINO (Lbs) |
|
| Sisäänvedetty | Pidennetty | ||||||
| Twwth30-1504 | 1 " | 1,5 "x4" | 11 " | 15 " | SAE#6 | 5/8 " | 7 |
| Twwth30-1506 | 1,5 "x6" | 13 " | 19 " | 8 | |||
| Twwth30-1508 | 1,5 "x8" | 15 " | 23 " | 9 | |||
| Twwth30-1510 | 1,5 “x10” | 17 " | 27 " | 11 | |||
| Twwth30-1512 | 1,5 "x12" | 19 " | 31 " | 12 | |||
| Twwth30-1514 | 1,5 "x14" | 21 ” | 35 " | 13 | |||
| Twwth30-1516 | 1,5 "x16" | 23 " | 39 " | 14 | |||
| Twwth30-2004 | 1-1/4 " | 2 "x4" | 12 " | 16 " | SAE#8 | 3/4 " | 10 |
| Twwth30-2006 | 2 "x6" | 14 " | 20 " | 12 | |||
| Twwth30-2008 | 2 "x8" | 16 " | 24 " | 14 | |||
| TWWT330-2010 | 2 “x10” | 18 " | 28 " | 16 | |||
| TWWT330-2012 | 2 "x12" | 20 " | 32 " | 17 | |||
| TWWT330-2014 | 2 "x14" | 22 " | 36 " | 19 | |||
| TWWT330-2016 | 2 "x16" | 24 " | 40 " | 21 | |||
| TWWT330-2018 | 2 "x18" | 26 " | 44 " | 22 | |||
| TWWT330-2020 | 2 "x20" | 28 " | 48 " | 24 | |||
| TWWT330-2024 | 2 "x24" | 32 " | 56 " | 27 | |||
| TWWT330-2028 | 2 "x28" | 36 " | 64 " | 31 | |||
| TWWT330-2030 | 2 "x30" | 38 " | 68 " | 33 | |||
| TWWT330-2032 | 2 "x32" | 40 " | 72 " | 34 | |||
| TWWT330-2036 | 2 "x36" | 44 " | 80 " | 38 | |||
| TWWT330-2040 | 2 "x40" | 48 " | 88 " | 41 | |||
| TWWT330-2042 | 2 "x42" | 50 " | 92 " | 43 | |||
| TWWT330-2048 | 2 "x48" | 56 " | 104 " | 48 | |||
| TWWT330-2060 | 2 "x60" | 68 " | 128 " | 58 | |||
| TWWT330-2072 | 2 "x72" | 80 " | 152 " | 68 | |||
| Hitsattu reiän sylinterin läpi | |||||||
| Osanumero | Sauva HALKAISIJA |
Poraus & Sidos |
MITAT | Satamakoko | Nasta KOKO |
PAINO (Lbs) |
|
| Sisäänvedetty | Pidennetty | ||||||
| Twwth30-2504 | 1-3/8 " | 2,5 "x4" | 12 " | 16 " | SAE#8 | 3/4 " | 14 |
| Twwth30-2506 | 2,5 "x6" | 14 " | 20 " | 16 | |||
| Twwth30-2508 | 2,5 "x8" | 16 " | 24 " | 18 | |||
| Twwth30-2510 | 2,5 “x10” | 18 " | 28 " | 20 | |||
| Twwth30-2512 | 2,5 "x12" | 20 " | 32 " | 22 | |||
| Twwth30-2514 | 2,5 "x14" | 22 " | 36 " | 24 | |||
| Twwth30-2516 | 2,5 "x16" | 24 " | 40 ” | 26 | |||
| Twwth30-2518 | 2,5 "x18" | 26 " | 44 " | 28 | |||
| Twwth30-2520 | 2,5 "x20" | 28 " | 48 " | 30 | |||
| Twwth30-2524 | 2,5 "x24" | 32 " | 56 " | 35 | |||
| Twwth30-2528 | 2,5 "x28" | 36 " | 64 " | 39 | |||
| Twwth30-2530 | 2,5 "x30" | 38 " | 68 " | 41 | |||
| Twwth30-2532 | 2,5 "x32" | 40 " | 72 ” | 43 | |||
| Twwth30-2536 | 2,5 "x36" " | 44 " | 80 " | 47 | |||
| Twwth30-2540 | 2,5 "x40" | 48 " | 88 " | 51 | |||
| Twwth30-2542 | 2,5 "x42" | 50 " | 92 " | 53 | |||
| Twwth30-2548 | 2,5 "x48" | 56 " | 104 " | 59 | |||
| Twwth30-2560 | 2,5 "x60" | 68 " | 128 " | 72 | |||
| TWWT330-3004 | 1-1/2 " | 3 "x4" | 12 " | 16 " | SAE#8 | 1 " | 19 |
| TWWT330-3006 | 3 "x6" | 14 " | 20 " | 21 | |||
| TWWT330-3008 | 3 "x8" | 16 " | 24 " | 24 | |||
| TWWT330-3010 | 3 “x10” | 18 " | 28 " | 26 | |||
| TWWT330-3012 | 3 "x12" | 20 " | 32 " | 28 | |||
| TWWT330-3014 | 3 "x14" | 22 " | 36 " | 31 | |||
| TWWT330-3016 | 3 "x16" | 24 " | 40 " | 33 | |||
| TWWT330-3018 | 3 "x18" | 26 " | 44 " | 36 | |||
| TWWT330-3020 | 3 "x20" | 28 " | 48 " | 38 | |||
| Twwth30-3024 | 3 "x24" | 32 " | 56 " | 43 | |||
| TWWT330-3028 | 3 "x28" | 36 " | 64 " | 48 | |||
| Twwth30-3030 | 3 "x30" | 38 " | 68 " | 51 | |||
| TWWT330-3032 | 3 "x32" | 40 " | 72 " | 53 | |||
| TWWT330-3036 | 3 "x36" | 44 " | 80 " | 58 | |||
| TWWT330-3040 | 3 "x40" | 48 " | 88 " | 63 | |||
| Twwth30-3042 | 3 "x42" | 50 " | 92 ” | 65 | |||
| Twwth30-3048 | 3 "x48" | 56 " | 104 " | 73 | |||
| TWWT330-3060 | 3 "x60" | 68 " | 128 " | 87 | |||
| Hitsattu reikän sylinterinen der | |||||||
| Osanumero | Sauva HALKAISIJA |
Poraus & Sidos |
MITAT | Satamakoko | Nasta KOKO |
PAINO (Lbs) |
|
| Sisäänvedetty | Pidennetty | ||||||
| TWWT330-3504 | 1-3/4 " | 3,5 "x4" | 12 " | 16 " | SAE#8 | 1 " | 24 |
| TWWT330-3506 | 3,5 "x6" | 14 " | 20 " | 27 | |||
| TWWT330-3508 | 3,5 "x8" | 16 " | 24 " | 30 | |||
| TWWT330-3510 | 3,5 "x10" | 18 " | 28 " | 33 | |||
| TWWT330-3512 | 3,5 "x12" | 20 " | 32 " | 36 | |||
| TWWT330-3514 | 3,5 "x14" | 22 " | 36 " | 39 | |||
| TWWT330-3516 | 3,5 "x16" | 24 " | 40 " | 42 | |||
| TWWT330-3518 | 3,5 "x18" | 26 " | 44 " | 45 | |||
| TWWT330-3520 | 3,5 "x20" | 28 " | 48 " | 48 | |||
| TWWT330-3524 | 3,5 "x24" | 32 " | 56 " | 54 | |||
| Twwth30-3528 | 3,5 "x28" | 36 " | 64 " | 60 | |||
| Twwth30-3530 | 3,5 "x30" | 38 " | 68 " | 63 | |||
| Twwth30-3532 | 3,5 "x32" | 40 " | 72 " | 66 | |||
| TWWT330-3536 | 3,5 "x36" | 44 " | 80 " | 72 | |||
| TWWT330-3540 | 3,5 "x40" | 48 " | 88 " | 79 | |||
| TWWT330-3542 | 3,5 "x42" | 50 " | 92 " | 82 | |||
| Twwth30-3548 | 3,5 "x48" | 56 " | 104 " | 91 | |||
| TWWT330-3560 | 3,5 "x60" | 68 " | 128 " | 109 | |||
| Twwth30-4004 | 2 " | 4,0 "x4" | 13 " | 17 " | SAE#8 | 1-1/4 " | 33 |
| TWWT330-4006 | 4,0 "x6" | 15 " | 21 " | 36 | |||
| TWWT330-4008 | 4,0 "x8" | 17 " | 25 " | 40 | |||
| TWWT330-4010 | 4.0 “x10” | 19 " | 29 " | 44 | |||
| TWWT330-4012 | 4,0 "x12" | 21 " | 33 " | 47 | |||
| TWWT330-4014 | 4,0 "x14" | 23 " | 37 " | 51 | |||
| TWWT330-4016 | 40 "x16" | 25 " | 41 " | 55 | |||
| TWWT330-4018 | 4,0 "x18" | 27 " | 45 " | 58 | |||
| TWWT330-4020 | 4,0 "x20" | 29 " | 49 " | 62 | |||
| Twwth30-4024 | 4,0 "x24" | 33 " | 57 " | 70 | |||
| TWWT330-4028 | 4,0 "x28" | 37 " | 65 " | 77 | |||
| TWWT330-4030 | 4,0 "x30" | 39 " | 69 " | 81 | |||
| TWWT330-4032 | 4,0 "x32" | 41 " | 73 " | 84 | |||
| Twwth30-4036 | 4,0 "x36" | 45 " | 81 " | 92 | |||
| TWWT330-4040 | 4,0 "x40" | 49 " | 89 " | 99 | |||
| Twwth30-4042 | 4,0 "x42" | 51 " | 93 " | 103 | |||
| Twwth30-4048 | 4,0 "x48" | 57 " | 105 " | 114 | |||
| TWWT330-4060 | 4,0 "x60" | 69 " | 129 " | 136 | |||
Tavalliset WTH -sarjan hitsatut hydraulisylinterin yksityiskohdat
